Mastering Digital Electronics

Discover the essential knowledge and practical skills to excel in the dynamic field of digital electronics with "Mastering Digital Electronics." From the fundamentals of diode resistor logic to unraveling the intricacies of TTL and CMOS logic gates, this book takes you on a journey through the evolution of digital electronics. Starting with the humble SR latch and progressing to the revolutionary JK flip flop that powers today's computer technology, you'll gain a solid foundation in binary arithmetic, Boolean algebra, and the representation and optimization of digital circuits.

The book gives a firm understanding of digital electronics, then moves on to using standard design methods, such as state diagrams, to design everyday logic circuits such as counters, shift registers, PISO, and SIPO registers. It delves into how to design some challenging digital circuits such as a crossroad set of traffic lights with a pelican crossing and how to use the 555 timer to controla variety of applications. At every stage of the book, you will be learning how to use TINA version 12, an industry standard ECAD and many of its functions. Moreover, the book ventures into using the software to simulate and so confirm all the circuits you design.

For readers interested in advancing to the practical implementation of the circuits discussed, the book provides opportunities to design PCB circuit boards for selected circuits using the software. This book will suit any student of digital electronics at any level and provide them with essential reference material for them to start a career in digital electronics.

What You'll Learn

• What logic gates are, and the difference between sequential and combinational logic.
• How to use binary numbers and how to perform all arithmetic operations
• Learn about the five basic logic gates; AND, NAND, OR, NOR and EXOR gates.
• How tominimize logic circuits using Boolean algebra and Karnaugh maps.
• How to state diagrams to design logic circuits.
• How to design a range of logic circuits.
• Learn about combinational circuits and the half and full adder as well as a logic circuit to subtract binary numbers.
• Learn about the 555 timer and how to apply it to a range of logic circuits.

Who This Book Is For

Students who are studying for an engineering qualification. Hobbyist who wants to design digital

circuits Engineers who need a go-to reference book on digital electronics.

Chapter 1 Introduction to The Logic Gate. - Chapter 2 Boolean Algebra. - Chapter 3 Simplifying Boolean Expressions. - Chapter 4 Moving on From the NAND Gate. - Chapter 5 Design Methods for Digital Circuits. - Chapter 6 State Diagrams. - Chapter 7 Combinational Logic Circuits. - Chapter 8 Shift Registers and More. - Chapter 9 Designing Some Useful Logic Circuits. - Chapter 10 Introduction to The 555 Timer modified 070923. - Chapter 11 Using TINA 12.
